TAS5000

· True Digital Audio Amplifier
· High Quality Audio
· 16-, 20-, or 24 Bit Input Data
· Sampling Rates: 44.1 kHz, 48 kHz, 88.2 kHz, and 96 kHz
· Supports Master and Slave Modes
· 90 dB SNR (EIAJ) and Dynamic Range at the Speaker Terminals
· 3.3 V Power Supply Operation
· Economical 48-Pin TQFP Package
· Digital De-Emphasis: 44.1 kHz and 48 kHz
· High Power Efficiency
· Clock Oscillator Circuit for Master Modes
· Low Jitter Internal PLL
· Mute
· Good Phase Characteristics
· Excellent PSRR

Analog supply voltage range, AV_DD1, AV_DD2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3 V to 4.2 V
Digital power supply voltage, DV_DD1, DV_DD2, DV_{DD3_L}, DV_{DD3_R} . . . . . . . . . . . . . . . . . . . . . 0.3 V to 4.2 V
Digital input voltage, V_I (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . . . 0.3 V to DV_DDX+0.3 V
Operating free-air temperature, T_A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . . . . . . 0 to 70
Storage temperature, T_stg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . 65 to 150
ESD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2000 V
Stresses beyond those listed under "absolute maximum ratings" may cause permanent damage to the device. These are stress ratings only and functional operation of the device at these or any other conditions beyond those indicated under "recommended operating conditions" is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES: 1. DVDD1, DVDD2, DVDD3_L, DVDD3_R

The serial audio port consists of a shift clock (SCLK pin), a left/right frame synchronization clock (LRCLK pin), and a data input (SDIN pin).

The serial audio port supports standard serial PCM formats (Fs = 44.1 kHz, 48 kHz, 88.2 kHz,or 96 kHz) stereo of the TAS5000. See section 2.8 for Serial Interface Formats.
