SVM7561

• Number of songs : Up to 16 songs
• Melody ROM : 512 steps (containing main melodies and accompaniments)
• Sound source : Two sounds (Square waves)
• Compass : One pattern can be selected by the mask option out of the four patterns of C4 to G6/C3 to G5/C4 to C7#/C3# to C6#
• Musical interval : 16 sounds of main melodies and accompaniments in the selected compass.
• Music selection : Serial selection with a terminal
• Sound generator : Speaker drive (External amplifier)
• Oscillator : Built-in CR oscillation/External input (to be selected by mask option)
• Play mode : Level hold/One shot (to be selected by mask option) SOP3A-8pin
• Shipping pattern : SOP3A-8Pin package
• Low voltage operation : • Low power oscillator depending on the built-in voltage stabilizer
                                         • Standby mode in which the internal IC circuits stop when no music is played.
• Power supply voltage : 0.9 to 5.5V
• Current consumption : • Target 1.0µA (during standby)
                                       • Target 200µA (during operation)
