SPM-7600G

Features: `1-Fiber Bi-Directional SFP Optical Transceiver`Simplex SC Connector: SPM-7600G`Simplex LC Connector: SPM-7600LG`1310 nm LD Transmitter`1550 nm Receiver`500 m links with 62.5/125 mm MMF Cables`500 m links with 50/125 mm MMF Cables`AC/AC Coupling according to MSA`RoHS Compliant`0 to 70oC ...

product image

SPM-7600G Picture
See larger image
SeekIC No. : 004501263 Detail

SPM-7600G: Features: `1-Fiber Bi-Directional SFP Optical Transceiver`Simplex SC Connector: SPM-7600G`Simplex LC Connector: SPM-7600LG`1310 nm LD Transmitter`1550 nm Receiver`500 m links with 62.5/125 mm MMF Ca...

SPM-7600G Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SPM-7600G
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

`1-Fiber Bi-Directional SFP Optical Transceiver
`Simplex SC Connector: SPM-7600G
`Simplex LC Connector: SPM-7600LG
`1310 nm LD Transmitter
`1550 nm Receiver
`500 m links with 62.5/125 mm MMF Cables
`500 m links with 50/125 mm MMF Cables
`AC/AC Coupling according to MSA
`RoHS Compliant
`0 to 70oC Operating : SPM-7600G
`-10 to 85 Operating : SPM-7600BG
`-40 to 85 Operating : SPM-7600AG
`Class 1 Laser International Safety Standard IEC 60825 Compliant


Application

·WDM Fast Ethernet Links
·IEEE 802.3ah 1000BASE-BX Applications
·Fibre Channel Links


Specifications

Parameter Symbol Min Max Units Notes
Storage Temperature Tstg -40 85
Operating Case Temperature Topr 0
-10
-40		 70
85
85
 SPM-7600G
SPM-7600BG
SPM-7600AG
Power Supply Voltage Vcc 0 3.6 V
Input Voltage --- GND Vcc V
Output Current Iout 0 30 mA



Description

The SPM-7600G series is small form factor pluggable module for multi-mode fiber Gigabit Ethernet and Fibre Channel single fiber communications by using 1310 nm transmitter and 1550 nm receiver. It is with the SFP 20-pin connector to allow hot plug capability. The transmitter section uses a multiple quantum well 1310 nm laser and is a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section SPM-7600G uses an integrated 1550 nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.
