SMS7621 Series

• Tight Parameter Distribution
• Available as Singles and Pairs
• 100% DC Tested
• Designed for High Volume Commercial Applications
• Available in Tape and Reel Packaging

Surface Mount Mixer and Detector Schottky Diodes

These SMS7621 Series low cost, surface mountable plastic packaged silicon mixer Schottky diodes are designed for RF and microwave mixers and detectors. SMS7621 Series include low barrier diodes and zero bias detectors, combining Skyworks' advanced semiconductor technology with low cost packaging techniques. All diodes are 100% DC tested and deliver tight parameter distribution, minimizing performance variability.SMS7621 Seriesy are available in SC- 70, SC-79, SOD-323, SOT-23 and SOT-143 packages. Wiring configurations include singles, common cathode, series pairs and unconnected pairs. Applications include low noise receivers used in high sensitivity ID tags, wireless systems, radio designs and may be used at frequencies to 10 GHz. SPICE model parameters are included as a design tool.
