SLR2016

Common Pin :
Operating Voltage :
Operating Current :
Packaging :
Illumination Color : Red
Maximum Operating Temperature : + 85 C
Minimum Operating Temperature : - 40 C
Wavelength : 660 nm
Display Type : 5 x 7 Dot Matrix
Number of Digits : 4
Character Size : 0.18 in


Features:

• Very Close Multi-line Spacing, 0.4" Centers
• 0.180" 5 x 7 Dot Matrix Characters
• 128 Special ASCII Characters for English,German, Italian, Swedish, Danish, andNorwegian Languages
• Wide Viewing Angle: X axis 50°Maximum,Y Axis ±75°Maximum
• Fast Access Time, 110 ns at 25°C
• Full Size Display for Stationary Equipment
• Built-in Memory
• Built-in Character Generator
• Built-in Multiplex and LED Drive Circuitry
• Direct Access to Each Digit Independently andAsynchronously
• Clear Function that Clears Character Memory
• True Blanking for Intensity Dimming Applications
• End-stackable, 4-Character Package
• Intensity Coded for Display Uniformity
• Extended Operating Temperature Range: 40°C to+85°C
• Superior ESD Immunity
• 100% Burned-in and Tested
• Wave Solderable
• TTL Compatible over Operating Temperature Range


Specifications

DC Supply Voltage.......................................0.5 V to +7.0 Vdc
Input Voltage, Respect to GND
(all inputs)...........................................  0.5 V toVCC+0.5 Vdc
Operating Temperature ................................ 40°C to +85°C
Storage Temperature...................................40°C to +100°C
Relative Humidity at 85°C ................................................85%
Maximum Solder Temperature, 0.063" (1.59 mm)
below Seating Plane, t<5.0 s ........................................260°C


Description

The SLR/SLO/SLG/SLY2016 is a four digit 5 x 7 dot matrix display module with a built-in CMOS integrated circuit. This display is X/Y stackable.

The SLR/SLO/SLG/SLY2016 integrated circuit contains memory, a 128 ASCII ROM decoder, multiplexing circuitry and drivers. Data entry is asynchronous. A display system can be built using any number of SLR/SLO/SLG/SLY2016 since each digit can be addressed independently and will continue to display the character last stored until replaced by another.

System interconnection is very straightforward. Two address bits (A0, A1) are normally connected to the like-named inputs of all displays in the system.

Data lines are connected to all SLR/SLO/SLG/SLY2016s directly and in parallel as is the write line (WR). The display will then behave as a write-only memory.

The SLR/SLO/SLG/SLY2016 has several features superior to competitive devices. 100% burn-in processing insures that the SLR/SLO/SLG/ SLY2016 will function in more stressful assembly and use environments. True "blanking" allows the designer to dim the display for more flexibility of display presentation. Finally the CLR clear function will clear the ASCII character RAM.

Parameters:

Technical/Catalog Information	SLR2016
Vendor	OSRAM Opto Semiconductors Inc
Category	Optoelectronics
Color	Red
Size / Dimension	0.78" L x 0.40" W x 0.20" H (19.91mm x 10.16mm x 5.08mm)
Millicandela Rating	-
Configuration	-
Voltage - Forward (Vf) Typ	-
Internal Connection	-
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	SLR2016 SLR2016 475 2575 ND 4752575ND 475-2575
