SK53

Features: • Plastic package has Underwriters LaboratoryFlammability Classification 94V-O• For surface mounted applications• Low profile package• Built-in strain relief• Metal to silicon rectifier. majority carrier conduction• Low power loss,high efficiency•...

product image

SK53 Picture
See larger image
SeekIC No. : 004491874 Detail

SK53: Features: • Plastic package has Underwriters LaboratoryFlammability Classification 94V-O• For surface mounted applications• Low profile package• Built-in strain relief•...

SK53 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SK53
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Plastic package has Underwriters Laboratory
Flammability Classification 94V-O
• For surface mounted applications
• Low profile package
• Built-in strain relief
• Metal to silicon rectifier. majority carrier conduction
• Low power loss,high efficiency
• High surge capacity
• For use in low voltage high frequency inverters, free wheeling, and polarity protection applications
• High temperature soldering guaranteed: 260°C /10 seconds at terminals




Specifications

SYMBOLS
SK52
SK53
SK54
SK55
SK56
SK58
SK59
S510
UNITS
Maximum Recurrent Peak Reverse Voltage
VRRM
20.0
30.0
40.0
50.0
60.0
80.0
90.0
100.0
V
Maximum RMS Voltage
VRMS
14.0
21.0
28.0
35.0
42.0
56.0
63.0
70.0
V
Maximum DC Blocking Voltage
VDC
20.0
30.0
40.0
50.0
60.0
80.0
90.0
100.0
V
Maximum Average Forward Rectified Current
at TL (See figure 1)
I(AV)
5.0
A
Peak Forward Surge Current 8.3ms single half sine-wave
superimposed on rated load (JEDEC method)
IFSM
100.0
A
Maximum Instantaneous Forward Voltage at 5.0A (Note 1)
VF
0.50
0.75
0.85
V
Maximum DC Reverse Current (Note 1) Ta= 25°C
at Rated DC Blocking Voltage Ta=100°C
IR
0.5
20.0
mA
Maximum Thermal Resistance(Note 2)
RJL
RJA
17.0
55.0
/W
Operating and Storage Temperature Range TJ
TJ
-50 to +125
Storage Temperature Range
TSTG
-55 to +150

NOTES:
A.Pulse Test with PW =300sec, 2% Duty Cycle.
B.Mounted on P.C. Board with 14mm2 (.013mm thick) copper pad areas.
