SK040NTP

On-State RMS Current (It RMS) :
Forward Voltage Drop :
Maximum Gate Peak Inverse Voltage :
Gate Trigger Voltage (Vgt) : 1.5 V
Mounting Style : SMD/SMT
Packaging : Tube
Package / Case : TO-263
Gate Trigger Current (Igt) : 40 mA
Holding Current (Ih Max) : 60 mA
Breakover Current IBO Max : 520 A
Off-State Leakage Current @ VDRM IDRM : 0.03 mA
Rated Repetitive Off-State Voltage VDRM : 1000 V


Parameters:

Technical/Catalog Information	SK040NTP
Vendor	Littelfuse / Teccor Brand Thyristors
Category	Discrete Semiconductor Products
SCR Type	Standard Recovery
Voltage - Off State	1000V
Current - On State (It (RMS) (Max)	40A
Current - On State (It (AV)) (Max)	25A
Current - Gate Trigger (Igt) (Max)	40mA
Current - Hold (Ih) (Max)	60mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	430A, 520A
Voltage - Gate Trigger (Vgt) (Max)	1.5V
Mounting Type	Surface Mount
Package / Case	D²Pak, SMD-220, TO-263 (2 leads + tab)
Packaging	Tube
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	SK040NTP SK040NTP
