Features: `RDS(on) (Max 0.0135 )@VGS=10V RDS(on) (Max 0.020 )@VGS=4.5V`Gate Charge (Typical 33nC)`Maximum Junction Temperature Range (150°C)`Available in Tape and ReelSpecifications Symbol Parameter Value Units VDSS Drain to Source Voltage 30 V ID Continuous Dra...
SFS4410: Features: `RDS(on) (Max 0.0135 )@VGS=10V RDS(on) (Max 0.020 )@VGS=4.5V`Gate Charge (Typical 33nC)`Maximum Junction Temperature Range (150°C)`Available in Tape and ReelSpecifications Symbol ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
` RDS(on) (Max 0.0135 )@VGS=10V
RDS(on) (Max 0.020 )@VGS=4.5V
` Gate Charge (Typical 33nC)
` Maximum Junction Temperature Range (150°C)
` Available in Tape and Reel
Symbol |
Parameter |
Value |
Units |
VDSS |
Drain to Source Voltage |
30 |
V |
ID |
Continuous Drain Current (@ TA=25) |
10 |
A
|
IDM |
Drain Current Pulsed (Note 1) |
50 |
A |
VGS |
Gate to Source Voltage |
±20 |
V |
PD |
Total Power Dissipation Single Operation( TA=25) |
2.5 |
W |
Total Power Dissipation Single Operation( TA=70) |
1.6 |
W | |
TSTG,TJ |
Operating Junction Temperature & Storage Temperature |
- 55 ~ 150 |
°C |
TL |
Maximum Lead Temperature for soldering purpose, 1/8 from Case for 5 seconds. |
300 |
°C |
