SF808G

Rectifiers 8A,600V,GLASS Pass, Superfast,Sgl Rect

product image

SF808G Picture
See larger image
SeekIC No. : 00173089 Detail

SF808G: Rectifiers 8A,600V,GLASS Pass, Superfast,Sgl Rect

SF808G Data Sheet

floor Price/Ceiling Price

US $ .2~.25 / Piece | Get Latest Price
Part Number:
SF808G
Mfg:
Taiwan Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1000
  • 1000~3000
  • 3000~5000
  • Unit Price
  • $.25
  • $.22
  • $.2
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Packaging : Tube

Description

Product :
Configuration :
Reverse Voltage :
Forward Voltage Drop :
Recovery Time :
Forward Continuous Current :
Max Surge Current :
Reverse Current IR :
Mounting Style :
Package / Case :
Packaging : Tube


Features:

· Low forward voltage drop
· High current capability
· High reliability
· High surge current capability


Specifications

Rating at 25ambient temperature unless otherwise specified.Single phase, half wave, 60 Hz, resistive or inductive load.For capacitive load, derate current by 20%

TYPE NUMBER
SYMBOL
SF
801G
SF
802G
SF
803G
SF
804G
SF
805G
SF
806G
SF
807G
SF
808G
UNITS
Maximum Recurrent Peak Reverse Voltage
VRRM
50
100
150
200
300
400
500
600
V
Maximum RMS Voltage
VRMS
35
70
105
140
210
280
350
420
V
Maximum DC Blocking Voltage
VDC
50
100

150
200
300
400
500
600
V

Maximum Average Forward Rectified
Current at Tc = 100
I(AV)
8.0
A
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated Load (JEDEC method )
IFSM
125
A
Typical Thermal Resistance@4.0A
VF
1.0
1.3
1.7
V
Maximum DC Reverse Current @ TA=25
at Rated DC Blocking Voltage @ TA=100
IR

10
400
uA
Maximum Reverse Recovery Time (Note 1)
Trr
35
ns
Typical Junction Capacitance (Note 2)
CJ
70
50
pF
Typical Thermal Resistance (Note 3)
RJC
3
/W
Operating and Storage Temperature Range
TJ,TSTG
-65 to +150

Notes: 1. Reverse Recovery Test Conditions: IF=0.5A, IR=1.0A, IRR=0.25A
            2. Measured at 1 MHz and Applied Reverse Voltage of 4.0 V D.C.
            3. Thermal Resistance from Junction to Case Mounted on Heatsink. Size of 2 in x 3 in x 0.25 in, Al-Plate.
