SF62

Rectifiers 6.0 Amp 100V 35ns

product image

SF62 Picture
See larger image
SeekIC No. : 00181491 Detail

SF62: Rectifiers 6.0 Amp 100V 35ns

SF62 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SF62
Mfg:
Taiwan Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Ultra Fast Recovery Rectifiers Configuration : Single
Reverse Voltage : 100 V Forward Voltage Drop : 0.975 V
Recovery Time : 35 ns Forward Continuous Current : 6 A
Max Surge Current : 150 A Reverse Current IR : 5 uA
Mounting Style : Through Hole Package / Case : DO-201AD
Packaging : Reel

Description

Product : Ultra Fast Recovery Rectifiers
Packaging : Reel
Configuration : Single
Reverse Current IR : 5 uA
Mounting Style : Through Hole
Forward Continuous Current : 6 A
Max Surge Current : 150 A
Reverse Voltage : 100 V
Package / Case : DO-201AD
Forward Voltage Drop : 0.975 V
Recovery Time : 35 ns


Features:

· Diffused Junction
· Low Forward Voltage Drop
· High Current Capability
· High Reliability
· High Surge Current Capabil


Specifications

Single Phase, half wave, 60Hz, resistive or inductive load.For capacitive load, derate current by 20%.
RATINGS
 Symbols
SF61
SF62
SF63
SF64
SF65
SF66
Units
Maximum repetitive peakreverse voltage
VRRM
50
100
150
200
300
400
V
Maximum RMS volts
VRWM
50
100
150
200
300
400
V
Maximum DC Blocking Voltage
VR
50
100
150
200
300
400
V
RMS Reverse Voltage
VR(RMS)
35
70
100
140
210
280
V
Maximum average forward current (Note 1) at TA=50
IO
6.0
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single half sine-wave superimposed on rated load
(JEDEC Method)
IFSM
150
A
Maximum forward voltage at@IF=6.0A
VFM
0.975
1.3
V
Maximum DC Reverse Current @ TA=25
at Rated DC Blocking Voltage @ TA=100
IRM

5.0
100
A
Reverse Recovery Time (Note 2)
Trr
35
ns
Typical Junction Capacitance (Note 3)
Cj
120
60
pF
Operating Temperature Range
TJ
-65 to +125
storage temperature range
TSTG
-65 to +150

*Glass passivated forms are available upon request
Note: 1. Leads maintained at ambient temperature at a distance of 9.5mm from the case
          2. Measured with IF = 0.5A, IR = 1.0A, IRR = 0.25A. See figure 5.
          3. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
