SF17SG

Rectifiers 1.0 Amp 500V 35ns

product image

SF17SG Picture
See larger image
SeekIC No. : 00175941 Detail

SF17SG: Rectifiers 1.0 Amp 500V 35ns

SF17SG Data Sheet

floor Price/Ceiling Price

US $ .05~.05 / Piece | Get Latest Price
Part Number:
SF17SG
Mfg:
Taiwan Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~5000
  • Unit Price
  • $.05
  • Processing time
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/11

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Ultra Fast Recovery Rectifiers Configuration : Single
Reverse Voltage : 500 V Forward Voltage Drop : 1.7 V
Recovery Time : 35 ns Forward Continuous Current : 1 A
Max Surge Current : 30 A Reverse Current IR : 5 uA
Mounting Style : Through Hole Package / Case : A-405
Packaging : Reel

Description

Product : Ultra Fast Recovery Rectifiers
Forward Continuous Current : 1 A
Max Surge Current : 30 A
Packaging : Reel
Configuration : Single
Reverse Current IR : 5 uA
Mounting Style : Through Hole
Recovery Time : 35 ns
Forward Voltage Drop : 1.7 V
Reverse Voltage : 500 V
Package / Case : A-405


Features:

· Low forward voltage drop
· High current capability
· High reliability
· High surge current capability


Specifications

Rating at 25ambient temperature unless otherwise specified.Single phase, half wave, 60 Hz, resistive or inductive load.For capacitive load, derate current by 20%

RATINGS
 Symbols SF11SG SF12SG SF13SG SF14SG SF15SG SF16SG SF17SG SF18SG Units
Maximum repetitive peakreverse voltage
VRRM
50
100
150
200
300
400
500
600
V
Maximum RMS volts
VRMS
35
70
105
140
210
280
350
420
V
Maximum DC blocking voltage
VDC
50
100
150
200
300
400
500
600
V
Maximum average forward rectified currentat @TA=55
I(AV)
1.0
A
Peak Forward Surge Current 8.3 ms single half sine-wave superimposed on rated load (JEDEC method)
IFSM
30
A
Maximum Instantaneous Forward Voltage
@ 1.0A
VF
0.95
1.3
1.7
V
Maximum DC Reverse Current at Rated DC Blocking Voltage@ TA=25
@ TA=125
IR
5.0
100
A
A
Maximum Reverse Recovery Time (Note 1)
Trr
35
ns
Typical Junction Capacitance (Note 2)
Cj
20
10
/W
Typical Thermal Resistance (Note 3)
RJA
95
pF
Operating Temperature Range
TJ
-65to+150
Storage Temperature Range
TSTG
-65to+150
Notes: 1. Reverse Recovery Test Conditions: IF=0.5A, IR=1.0A, IRR=0.25A
           2. Measured at 1 MHz and Applied Reverse Voltage of 4.0 V D.C.
           3. Mount on Cu-Pad Size 5mm x 5mm on PCB.
