Product Details

Description

Features:

Repetitive Peak Off-State Voltage : 600V
R.M.S On-State Current ( I _T(RMS) = 12 A )
Low On-State Voltage (1.3V(Typ.)@ I_TM)
Non-iosolated Type

Specifications

Symbol	Parameter	Condition	Ratings	Units
V_DRM	Repetitive Peak Off-State Voltage		600	V
I_T(AV)	Average On-State Current	Half Sine Wave : T_C= 109	7.6	A
I_T(RMS)	R.M.S On-State Current	180° Conduction Angl	12	A
I_TSM	Surge On-State Current	1/2 Cycle, 60Hz, Sine Wave Non-Repetitive	132	A
I²t	I² t for Fusing	t = 8.3ms	87	A²s
di/dt	Critical rate of rise of on-state current		50	A/s
P_GM	Forward Peak Gate Power Dissipation		5	W
P_G(AV)	Forward Average Gate Power Dissipation		0.5	W
I_FGM	Forward Peak Gate Current		2	A
V_RGM	Reverse Peak Gate Voltage		5.0	V
T_J	Operating Junction Temperature		- 40 ~ 125
T_STG	Storage Temperature		- 40 ~ 150

Description

Standard gate triggering SCR SCP12C60 is suitable for the application where requiring high bidirectional blocking voltage capability and also suitable for over voltage protection ,motor control circuit in power tool, inrush current limit circuit and heating control system.
