SBP1020T

The SBP1020T is designed as one kind of schottky rectifier with current 10 amperes.
SBP1020T has eight features. (1)Plastic package has underwriters laboratory flamability classification 94V-0 utilizing general. (2)Metal to silicon rectifier, majority carrier conduction. (3)Low power loss, high efficiency. (4)High current capability, low Vf. (5)High surge capability. (6)Epitaxial construction. (7)For use in low voltage, high frequency inverters, free wheeling and polarity protection applications. (8)Dual rectifier construction, positive center-tap. Those are all the main features.

Some absolute maximum ratings of SBP1020T have been concluded into several points as follow. (1)Its maximum recurrent peak reverse voltage would be 20V. (2)Its maximum RMS voltage would be 14V. (3)Its maximum DC blocking voltage would be 20V. (4)Its maximum average forward rectified current would be 10A. (5)Its peak forward surge current, 8.3ms single hlaf sine-wave superimposed on rated load (JEDEC method) would be 100A. (6)Its maximum instantaneous forward voltage would be 0.55V. (7)Its maximum average reverse current at Tc=25°C rated DC blocing voltage per element would be 3.5mA. (8)Its typical thermal resistance would be 3.0°C/W. (9)Its typical junction capacitance would be 650pF. (10)Its operating temperature range would be from -65°C to 125°C. (11)Its storage temperature range would be from -65°C to 150°C. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device.

Also some mechanical characteristics of SBP1020T are concluded as follow. (1)Its case would be TO-220 molded plastic. (2)Its terminals would be lead solderable per MIL-STD 202 method 208. (3)Its mounting position is any. (4)Its weight is 0.08 ounces, 2.24 grams. (5)Its polarity would be as marked. And so on. At present we have not got so much information about this IC and we would try hard to get more information about it. If you have any question or suggestion or want to know more information please contact us for details. Thank you!
