SB50-18K

· Low forward voltage (VF max=0.85V).
· Fast reverse recovery time (trr max=40ns).
· Low switching noise.
· Low leakage current and high reliability due tohighly reliable planar structure.

· High frequency rectification (switching regulators,converters, choppers).

Features of the SB50-18K are:(1)low forward voltage (VF max=0.85V);(2)fast reverse recovery time (trr max=40ns)(3)low switching noise;(4)low leakage current and high reliability due to highly reliable planar structure.

The absolute maximum ratings of the SB50-18K can be summarized as:(1):the characteristic is repetitive peak reverse voltage,the symbol is VRRM,the rating is 180,the unit is V;(2):the characteristic is nonrepetitive peak reverse surge voltage,the symbol is VRSM,the rating is 190,the unit is V;(3):the characteristic is average output current,the symbol is IO,the rating is 5,the unit is A;(4):the characteristic is surge forward current,the symbol is IFSM,the rating is 60,the unit is A;(5):the characteristic is junction temperature,the symbol is Tj,the rating is -55 to 125,the unit is ;(6):the characteristic is storage temperature,the symbol is Tstg,the rating is -55 to 125,the unit is .

The electrical characteristics of the SB50-18K can be summarized as:(1):the characteristic is forward voltage,the symbol is VF,the Max is 0.85,the unit is V;(2):the characteristic is reverse voltage,the symbol is VR,the Min is 180,the unit is V;(3):the characteristic is reverse current,the symbol is IR,the Max is 0.4,the unit is mA;(4):the characteristic is reverse recovery time,the symbol is trr,the Max is 40,the unit is ns;(5):the characteristic is thermal resistance,the symbol is Rthj-c,the Max is 2.5,the unit is /W.
