Product Details

Description

Features:

• Plastic package has Underwriters Laboratory Flammability Classification 94V-0
• Low power loss, high efficiency
• For use in low voltage high frequency inverters, free wheeling, and polarity protection applications
• Guardring for overvoltage protection
• High temperature soldering guaranteed: 250°C/10 seconds at terminals

Specifications

Parameter	SYMBOLS	SB220	SB230	SB240	SB250	S260	UNITS
Maximum repetitive peak reverse voltage	V_RRM	20	30	40	50	60	V
Maximum RMS voltage	V_RMS	14	21	28	35	42	V
Maximum DC blocking voltage	V_DC	20	30	40	50	60	V
Maximum average forward rectified current at 0.375" (9.5mm) lead length (See Fig. 1)	I_F(AV)	2.0					A
Peak forward surge current 8.3ms single half sine-wave superimposed on rated load (JEDEC Method)	I_FSM	60					A
Maximum Full Load Reverse Current, Full Cycle Average at TA = 75°C	I_R(AV)	30					mA
Typical thermal resistance (Note 2)	R_JA R_JL	45 14					°C/W
Operating junction temperature range	T_J	-65 to +125				-65 to +125	°C
Storage temperature range	T_STG	-65 to +150					°C
