S5K711LA

The S5K711CA and S5K711LA are highly integrated single chip CMOS image sensors fabricated by SAMSUNG 0.35mm CMOS image sensor process technology. It is developed for imaging application to realize high-efficiency and low-power photo sensor. The S5K711LA has 352 x 352 effective pixels with 1/7 inch optical format. The sensor has on-chip 8-bit ADC blocks to digitize the pixel output and also on-chip CDS to reduce Fixed Pattern Noise (FPN) drastically. With its few interface signals and 8-bit raw data directly connected to the external devices, a camera system can be configured easily. S5K711CA is suitable for a camera system with standard 3.3V logic operation and S5K711LA is suitable for low power camera module with 2.8V power supply.
