S2800C

The S2800C is designed as one kind of high voltage, medium current silicon controlled rectifiers for switching AC and DC currents.

S2800C has eight features. (1)800V, 125°C Tj operating. (2)High dv/dt and di/dt capability. (3)Low switching losses. (4)High pulse current capability. (5)Low forward and reverse leakage. (6)Sipos oxide glass multilayer passivation system. (7)Advanced unisurface construction. (8)Precise Ion implanted diffusion source. Those are all the main features.

Some absolute maximum ratings of S2800C have been concluded into several points as follow. (1)Its Vdrm and Vrrm would be 300V. (2)Its It(rms) would be 10A at Tc=100°C and =180°. (3)Its Itsm would be 100A for 1 full cycle. (4)Its di/dt would be 100A/us. (5)Its I2t would be 40A2s at 8.3ms. (6)Its Pgm for 10us max would be 16W. (7)Its Pg(av) would be 0.5W averaging time 10ms max. (8)Its storage temperature range would be from -65°C to 150°C. (9)Its operating junction temperature range would be from -65°C to 125°C. (10)Its Tt during soldering would be 250°C for 10s max terminals and case. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to S2800C.

Also some electrical characteristics of S2800C are concluded as follow. (1)Its Idrom or Irom would be typ 0.1mA and max 2mA. (2)Its Vt would be typ 1.7V and max 2V. (3)Its Igt would be typ 8mA and max 15mA. (4)Its Vgt would be typ 0.9V and max 1.5V. (5)Its Iho would be typ 10mA and max 20mA. (6)Its dv/dt would be min 40V/us. (7)Its tgt would be typ 1.6us and max 2.5us. (8)Its tq would be typ 10us and max 35us. (9)Its Rjc would be max 2°C/W. (10)Its Rja would be max 60°C/W. And so on. At present we have not got so much information about this IC and we would try hard to get more information about it. If you have any question or suggestion or want to know more information about  S2800C please contact us for details. Thank you!
