Product Details

Description

Features:

· Low operating current type (MAX 60mArms )
· Compact 5-pin dual-in-line package type
· Recognized by UL file No. E94758

Application

· Electrical dampers for refrigerator
· Turntable controllers for microwave oven
· Ignitions circuit for oil fan heater

Specifications

Parameter			Symbol	Rating	Unit
Inpu	Forward current		I_F	50	mA
Inpu	Reverse voltage		V_R	6	V
Output	RMS ON-state current		I_T	100	mArms
	^*1 Peak one cycle surge current		I_surge	1.2	A
	Repetitive peak OFF-state voltage	S11MA01	V_DRM	400	V
	Repetitive peak OFF-state voltage	S21MA01	V_DRM	600	V
^*2 Isolation voltage			V_iso	5 000	Vrms
Operating temperature			T_opr	- 25 to + 80
Storage temperature			T_stg	- 55 to + 125
^*3 Soldering temperature			T_sol	260

^*1 50Hz sine wave
^*2 AC for 1 minute, 40 to 60%RH, f=60Hz
^*3 For 10 seconds
