S1L9225X

• RF amplifier (CD, CD-R, CD-RW applicable)
• Gain setting & monitoring for the CD-R, CD-RW DISC
• Focus error amp & Febias adjustment
• Tracking error amp & balance, gain adjustment
• FOK, defect, mirror detect
• Center voltage amplifier
• APC (Automatic Power Control)
• APC laser controller (Controlled by Tracking Summing Signal)
• RF AGC & EQ control (AGC Level Control Compatible)
• Enhanced EFM slice (Double Asymmetry Method)
• Focus servo loop & offset adjustment
• Tracking servo loop & offset adjustment
• Sled servo loop
• Spindle servo loop
• Auto-sequence
• Fast search mode (1 - 36000 track jump)
• Interruption countermeasure
• Focus & Tracking servo muting controlled by EFM duty check
• RF peaking prevention system by EFM duty check
• Focus, tracking, spindle loop pole move option
• Operating voltage 2.7V ¾ 3.3V
• Power saving mode <Notice> LPC Control used by side beam signal, it related to pick-up assurance. When used pick-up, the specification is present extra.
