S1B

Forward Voltage Drop : 1.1 V
Mounting Style : SMD/SMT
Forward Continuous Current : 1 A
Reverse Current IR : 1 uA
Packaging : Reel
Configuration : Single
Product : Standard Recovery Rectifiers
Recovery Time : 1800 ns
Max Surge Current : 40 A
Package / Case : SMA
Reverse Voltage : 100 V


Specifications

Part Number	S1B
Total Capacitance CT (pF)	10
Max Average Rectified Current IO (A)	1
Peak Repetitive Reverse Voltage VRRM (V)	100
Peak Forward Surge Current IFSM (A)	30
Forward Voltage Drop VF (V)	1.1
Max Reverse Current IR (µA)	5

Product	Product status	Eco Status	Pricing*	Package type	Leads	Packing method	Package Drawing
S1B	Full Production	RoHS Compliant	$0.0408	DO-214AC(SMA)	2	TAPE REEL	TBD

* Fairchild 1,000 piece Budgetary Pricing

** A sample button will appear if the part is available through Fairchild's on-line samples program. If there is no sample button, please contact a Fairchild distributor to obtain samples

Description

DO-214AC surface mountable package with glass passivated chip.The well-defined void-free case is of a transfer-moulded thermo-setting plastic. The small rectangular package has two J bent leads.

DO-214AC has many unique features: The first one is glass passivated.The second one is high maximum operating temperature.The third one is it is ideal for surface mount automotive applications.The forth one is Low leakage current.The fifth one is The sixth one is excellent stability.The seventh one is UL 94V-O classified plastic package.The eighth one is guaranteed avalanche energy absorption capability.The ninth one is shipped in 12 mm embossed tape.The tenth one is easy pick and place.

Well,if you are interested in DO-214AC and want to know more, please pay more attention to our web for you will find more information about it. Thanks for your attention!

Parameters:

Technical/Catalog Information	S1B
Vendor	Fairchild Semiconductor (VA)
Category	Discrete Semiconductor Products
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	100V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	1.1V @ 1A
Reverse Recovery Time (trr)	1.8s
Current - Reverse Leakage @ Vr	1A @ 100V
Speed	Standard Recovery >500ns, > 200mA (Io)
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Packaging	Cut Tape (CT)
Capacitance @ Vr, F	12pF @ 4V, 1MHz
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	S1B S1B S1BFSCT ND S1BFSCTND S1BFSCT
