RS-1212D

Mounting Style :
Product : Isolated
Output Voltage (Channel 1) : 12 V
Number of Outputs : 2
Output Voltage (Channel 2) : - 12 V
Input Voltage (nominal) : 12 V
Output Power : 2 W
Output Current (Channel 1) : 83 mA
Output Current (Channel 2) : - 83 mA
Input Voltage Range : 9 V to 18 V
Package / Case Size : SIP-8


Features:

· 2:1 Wide Range Voltage Input
· 1kVDC, 2kVD & 3kVDC Isolation
· UL94V-0 Package Material
· Continuous Short Circuit Protection with Current Foldback
· Low Noise
· No External Capacitor needed
· Efficiency to 83%


Pinout




Description

High power-density covering the temperature range -40°C to +85°C, offering extra features like Remote- On-Off-function and Output-Filtering via 1 external capacitor only, are just some of the characteristics of this converter RS-1212D, ideal for highly sophisticated industrial-designs.The RS series RS-1212D is available with isolation of 2kV or 3kV by chosing option "/H2" or "/H3".
