RP1105

SpecificationsCharacteristic Symbol Minimum Typical Maximum Units Center Frequency Absolute Frequency fC 639.900 640.100 MHz Tolerance from 640.000 MHz ...

product image

RP1105 Picture
See larger image
SeekIC No. : 004478879 Detail

RP1105: SpecificationsCharacteristic Symbol Minimum Typical Maximum Units Center Frequency Absolute Frequency fC 639.900 ...

RP1105 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
RP1105
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Specifications

Characteristic Symbol Minimum Typical Maximum Units Center Frequency Absolute Frequency fC 639.900 640.100 MHz Tolerance from 640.000 MHz DfC 100 kHz Insertion Loss IL 9.1 12.5 dB Quality Factor Unloaded Q QU 8600 50 Ohm Loaded Q QL 5600 Temperature Stability Turnover Temperature TO 64 79 94 C Turnover Frequency fO fC+69 kHz Frequency Temp. Coefficient FTC 0.037 ppm/C2 Frequency Aging Absolute Value during First Year |fA| 10 ppm/yr DC Insulation Resistance between Any Two Pins 1.0 MOhm RF Equivalent RLC Motional Resistance RM 185 322 Ohm Motional Inductance LM 395.520 uH Motional Capacitance CM 0.156356 fF Shunt Static Capacitance CO 1.4 1.7 2.0 pF Lid Symbolization RP1105


Description

Ideal for 639.9 or 640.0 MHz Oscillators Nominal Insertion Phase Shift RP1105 of 180 at Resonance Quartz Stability Rugged, Hermetic, Low-Profile TO39 Case Complies with Directive 2002/95/EC (RoHS)
