QLx4600-S30

The QLx4600-S305 is a settable quad receive-side equalizer with extended functionality for advanced protocols operating with line rates up to 6.25Gb/s such as InfiniBand (SDR and DDR), PCI Express and 10GBase-CX4. The features of QLx4600-S30 are as follows: (1)Supports data rates up to 6.25Gb/s; (2)Low power (78mW per channel); (3)Low latency (<500ps); (4)Four equalizers in a 4mmx7mm QFN package for straight route-through architecture and simplified routing.

The following is about the absolute maximum ratings of QLx4600-S30: (1)Supply Voltage (VDD to GND): -0.3V to 1.3V; (2)Voltage at All Input Pins: -0.3V to VDD + 0.3V; (3)ESD Rating at All Pins: 2kV (HBM).

The electrical characteristics of the QLx4600-S30 are: (1)Supply Current: 260 mA; (2)Cable Input Amplitude Range: 800 to 1600 mVP-P at Measured differentially at data source before encountering channel loss; (3)DC Differential Input Resistance: 80 min, 100 typ and 120 max at Measured on input channel IN[P,N] ; (4)DC Single-Ended Input Resistance: 40 min, 50 typ and 60 max at Measured on input channel IN[P] or IN[N].
