Q48SL1R535

Features: ` High efficiency: 85% @ 1.5V/ 35A` Size: 57.9mmx36.8mmx12.7mm (2.28 x1.45 x0.50 )` Standard footprint` Industry standard pin out` Fixed frequency operation` Metal baseplate` Input UVLO, Output OCP, OVP, OTP` Basic insulation` No minimum load required` 2:1 Input voltage range` ISO 9001, ...

product image

Q48SL1R535 Picture
See larger image
SeekIC No. : 004467781 Detail

Q48SL1R535: Features: ` High efficiency: 85% @ 1.5V/ 35A` Size: 57.9mmx36.8mmx12.7mm (2.28 x1.45 x0.50 )` Standard footprint` Industry standard pin out` Fixed frequency operation` Metal baseplate` Input UVLO, O...

Q48SL1R535 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
Q48SL1R535
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` High efficiency: 85% @ 1.5V/ 35A
` Size: 57.9mmx36.8mmx12.7mm (2.28"x1.45"x0.50")
` Standard footprint
` Industry standard pin out
` Fixed frequency operation
` Metal baseplate
` Input UVLO, Output OCP, OVP, OTP
` Basic insulation
` No minimum load required
` 2:1 Input voltage range
` ISO 9001, TL 9000, ISO 14001, QS9000, OHSAS18001 certified manufacturing facility
` UL/cUL 60950 (US & Canada) Recognized, and TUV (EN60950) Certified
` CE mark meets 73/23/EEC and 93/68/EEC directives


Application

· Telecom/Datacom
· Wireless Networks
· Optical Network Equipment
·  Server and Data Storage
· Industrial/Testing Equipment


Specifications

PARAMETER
CONDITIONS
Min.
Max.
Units
Input Voltage
Continuous
85
Vdc
Transient (100ms) 100ms
100
Vdc
Operating Temperature Refer to Figure 21 for measuring point
-40
100
°C
Storage Temperature
-55
125
°C
Input/Output Isolation Voltage 1 minute
1500
Vdc



Description

The Delphi Series Q48SL1R535 Quarter Brick, 48V input, single output, isolated DC/DC converter is the latest offering from a world leader in power system and technology and manufacturing -- Delta Electronics, Inc. This product family provides up to 100 watts of power or 35A of output current (2.5V and below) in an industry standard footprint. With creative design technology and optimization of component placement, these converters possess outstanding electrical and thermal performances, as well as extremely high reliability under highly stressful operating conditions. All models are fully protected from abnormal input/output voltage, current, and temperature conditions. The Delphi Series converters Q48SL1R535 meet all safety requirements with basic insulation.
