SeekIC No. : 00202753 Detail

Q2035NH5TP: Triacs 200V 30A

Q2035NH5TP Data Sheet

US $ 1.45~1.77 / Piece | Get Latest Price

Part Number:: Q2035NH5TP
Mfg:: Littelfuse
Supply Ability:: 5000

Price Break

Qty
0~230
230~250
250~500
500~1000

Unit Price
$1.77
$1.6
$1.54
$1.45

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

Q2030LH5 evaluate
US $1.16 - 1.35 / Piece

Triacs 200V 30A
Q2035NH5RP evaluate
US $1.4 - 1.7 / Piece

Triacs 200V 30A
Q2035RH5 evaluate
US $1.16 - 1.34 / Piece

Triacs 200V 35A

Product Details

Quick Details

Rated Repetitive Off-State Voltage VDRM :	200 V	On-State RMS Current (It RMS) :	35 A
Off-State Leakage Current @ VDRM IDRM :	0.05 mA	Gate Trigger Voltage (Vgt) :	2 V
Gate Trigger Current (Igt) :	50 mA	Holding Current (Ih Max) :	75 mA
Mounting Style :	SMD/SMT	Package / Case :	TO-263
Packaging :	Tube

Description

Breakover Current IBO Max :
Gate Trigger Current (Igt) : 50 mA
Packaging : Tube
Mounting Style : SMD/SMT
Off-State Leakage Current @ VDRM IDRM : 0.05 mA
Holding Current (Ih Max) : 75 mA
Gate Trigger Voltage (Vgt) : 2 V
Package / Case : TO-263
On-State RMS Current (It RMS) : 35 A
Rated Repetitive Off-State Voltage VDRM : 200 V

Parameters:

Technical/Catalog Information	Q2035NH5TP
Vendor	Littelfuse / Teccor Brand Thyristors
Category	Discrete Semiconductor Products
Triac Type	Alternistor - Snubberless
Configuration	Single
Voltage - Off State	200V
Current - On State (It (RMS) (Max)	35A
Voltage - Gate Trigger (Vgt) (Max)	2V
Current - Gate Trigger (Igt) (Max)	50mA
Current - Hold (Ih) (Max)	75mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	290A, 350A
Mounting Type	Surface Mount
Package / Case	D²Pak, SMD-220, TO-263 (2 leads + tab)
Packaging	Tube
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	Q2035NH5TP Q2035NH5TP
