Output Type: AC, DC
Voltage - Load: 0 ~ 250 V
Mounting Type: Surface Mount
Termination Style: Gull Wing
Packaging: Tape & Reel (TR)
Relay Type: Relay
Voltage - Input: 1.2VDC
On-State Resistance: 10 Ohm
Load Current: 170mA
Circuit: DPST (2 Form A)
Package / Case: 8-SMD (0.300", 7.62mm)
Series: PVT, HEXFET®
Manufacturer: International Rectifier
Supplier Device Package: 8-SMT
Features: ·HEXFET Power MOSFET output
·Bounce-free operation
·4,000 VRMS I/O isolation
·Linear AC/DC operation
·Solid-State reliability
·UL recognition pending Application·On/Off Hook switch
·Tip and Ring Line switching
·General switching DescriptionThe PVT322S-T Series Photovoltaic Relay is a dualpole, normally open solid-state relay that can replace electromechanical relays in many applications. It utilizes International Rectifier's HEXFET power MOSFET as the output switch, driven by an integrated circuit photovoltaic generator of novel construction.
The output switch PVT322S-T is controlled by radiation from a GaAlAs light emitting diode (LED) which is optically isolated from the photovoltaic generator.
Series PVT322S-T Relays are packaged in an 8-pin, molded DIP package with either through-hole or surface mount (gull-wing) terminals. It is available in standard plastic shipping tubes or on tape-andreel. Please refer to Part Identification information opposite.
Parameters: | Technical/Catalog Information | PVT322S-T |
| Vendor | International Rectifier |
| Category | Relays |
| Mounting Type | Surface Mount |
| Termination Style | Gull Wing |
| Package / Case | 8-SMD (300 mil) |
| Circuit | DPST (2 Form A) |
| Load Current | 170mA |
| Voltage - Input | 1.2VDC |
| Voltage - Load | 0 ~ 250 V |
| Output Type | AC, DC |
| On-State Resistance | 10 Ohm |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | PVT322S T
PVT322ST
|
PVT322S-T Data Sheet
