PT6351

Features: • CMOS Technology• 28 High Voltage Output Ports: 8 to 16 Digit Ports 8 to 16 Segment Ports• 17 All-Purpose I/O Ports• 9 LED Drive Capable Ports• Display Modes: 8 DGT x 8 SG to 16 DGT x 12 SG or up to 12 DGT x 16 SG• 32 Bytes Display Data• Key Sca...

product image

PT6351 Picture
See larger image
SeekIC No. : 004466456 Detail

PT6351: Features: • CMOS Technology• 28 High Voltage Output Ports: 8 to 16 Digit Ports 8 to 16 Segment Ports• 17 All-Purpose I/O Ports• 9 LED Drive Capable Ports• Display Modes...

PT6351 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PT6351
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• CMOS Technology
• 28 High Voltage Output Ports: 8 to 16 Digit Ports
                                                   8 to 16 Segment Ports
• 17 All-Purpose I/O Ports
• 9 LED Drive Capable Ports
• Display Modes: 8 DGT x 8 SG to 16 DGT x 12 SG or up to 12 DGT x 16 SG
• 32 Bytes Display Data
• Key Scan Input: 5x12 (max.)
• Display ON/OFF Control
• Auto Scan Operation
• Power ON Reset Circuit
• Supply Voltage: Digital Section: VDD = 4.5 to 5.5 V
                                                     High Voltage: Vpp = VDD - 35 V
• Available in 44-pin, LQFP Package
• Functionally Compatible with MN12510F


Application

• Peripheral Device for Micro-Computer


Pinout

Connection Diagram


Description

PT6351 is a Vacuum Fluorescent Display Driver IC utilizing CMOS Technology. 28 High Voltage Ports, 17 All Purpose I/O Ports, 9 LED ports, Auto Scan Opera -tion, 4-line Serial Signal (with chip selector), 8 DGT x 8 SG to 16 DGT x 12 SG are all incorporated into a single chip to build a highly reliable peripheral device for a single chip microcomputer. It is housed in 44-pin LQFP Package and is functionally compatible with MN12510F.
