PNP2N6609

Features: • Pb−Free Packages are Available**• High Safe Operating Area (100% Tested) 150 W @ 100 V• Completely Characterized for Linear Operation• High DC Current Gain and Low Saturation Voltage hFE = 15 (Min) @ 8.0 A, 4.0 V VCE(sat) = 1.4 V (Max) @ IC = 8.0 A, IB = 0...

product image

PNP2N6609 Picture
See larger image
SeekIC No. : 004464359 Detail

PNP2N6609: Features: • Pb−Free Packages are Available**• High Safe Operating Area (100% Tested) 150 W @ 100 V• Completely Characterized for Linear Operation• High DC Current Gain ...

PNP2N6609 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PNP2N6609
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Pb−Free Packages are Available**
• High Safe Operating Area (100% Tested) 150 W @ 100 V
• Completely Characterized for Linear Operation
• High DC Current Gain and Low Saturation Voltage
       hFE = 15 (Min) @ 8.0 A, 4.0 V
       VCE(sat) = 1.4 V (Max) @ IC = 8.0 A, IB = 0.8 A
• For Low Distortion Complementary Designs


Specifications

Rating

Symbol

Value

Unit

Collector − Emitter Voltage

VCEO

140

Vdc

Collector − Emitter Voltage

VCEX

160

Vdc

Collector − Base Voltage

VCBO

160

Vdc

Emitter − Base Voltage

VEBO

7

Vdc

Collector Current
− Continuous
− Peak (Note 2)

IC

16
30

Adc

Base Current
− Continuous
− Peak (Note 2)

IB

4
15

Adc

Total Power Dissipation @ TA = 25°C
Derate above 25°C

PD

150
0.855

W
W/°C

Operating and Storage Junction
Temperature Range

TJ, Tstg

−65 to +200

°C




Description

The 2N3773 and 2N6609 are PowerBase™ power transistors designed for high power audio, disk head positioners and other linear applications. These devices can also be used in power switching circuits such as relay or solenoid drivers, DC−DC converters or inverters.
