PNA1401L

NPN PHOTOTRANSISTOR 800NM TO-18

product image

PNA1401L Picture
SeekIC No. : 004137344 Detail

PNA1401L: NPN PHOTOTRANSISTOR 800NM TO-18

floor Price/Ceiling Price

Part Number:
PNA1401L
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/11

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: * Manufacturer: Panasonic Electronic Components - Semiconductor Products
Maximum Operating Frequency : 27 MHz Voltage - Collector Emitter Breakdown (Max): 30V
Current - Collector (Ic) (Max): 50mA Current - Dark (Id) (Max): 300nA
Wavelength: 800nm Viewing Angle: 20°
Power - Max: 150mW Mounting Type: Through Hole
Orientation: Top View

Description

Series: *
Current - Collector (Ic) (Max): 50mA
Orientation: Top View
Mounting Type: Through Hole
Power - Max: 150mW
Viewing Angle: 20°
Wavelength: 800nm
Voltage - Collector Emitter Breakdown (Max): 30V
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Current - Dark (Id) (Max): 300nA
Package / Case: TO-18-2 Metal Can


Features:

`High sensitivity
`Wide spectral sensitivity, suited for detecting GaAs LED's
`Low dark current : ICEO = 5 nA (typ.)
`Fast response : tr, tf = 3 s (typ.)
`TO-18 standard type package



Specifications

Parameter Symbol Ratings Unit
Collector to base voltage VCBO 30 V
Emitter to collector voltage VEBO 5 V
Collector current IC 50 mA
Collector power dissipation PC 150 mW
Operating ambient temperature Topr 25 to +85 °C
Storage temperature Tstg 30 to +10 °C



Parameters:

Technical/Catalog InformationPNA1401L
VendorPanasonic - SSG
CategorySensors, Transducers
Voltage - Collector Emitter Breakdown (Max)30V
Current - Collector (Ic) (Max)50mA
Current - Dark (Id) (Max)300nA
Power - Max150mW
OrientationTop View
Mounting TypeThrough Hole
Package / CaseTO-18
Wavelength800nm
Viewing Angle20°
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names PNA1401L
PNA1401L
