PMV117EN,215

MOSFET TAPE13 PWR-MOS

product image

PMV117EN,215 Picture
See larger image
SeekIC No. : 00148881 Detail

PMV117EN,215: MOSFET TAPE13 PWR-MOS

PMV117EN,215 Data Sheet

floor Price/Ceiling Price

US $ .07~.09 / Piece | Get Latest Price
Part Number:
PMV117EN,215
Mfg:
NXP Semiconductors
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.09
  • $.08
  • $.08
  • $.07
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 30 V
Gate-Source Breakdown Voltage : +/- 20 V Continuous Drain Current : 2.5 A
Resistance Drain-Source RDS (on) : 117 mOhms Configuration : Single
Maximum Operating Temperature : + 150 C Mounting Style : SMD/SMT
Package / Case : SOT-23 Packaging : Reel

Description

Transistor Polarity : N-Channel
Gate-Source Breakdown Voltage : +/- 20 V
Configuration : Single
Mounting Style : SMD/SMT
Packaging : Reel
Drain-Source Breakdown Voltage : 30 V
Package / Case : SOT-23
Maximum Operating Temperature : + 150 C
Continuous Drain Current : 2.5 A
Resistance Drain-Source RDS (on) : 117 mOhms


Parameters:

Technical/Catalog InformationPMV117EN,215
VendorNXP Semiconductors
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET PolarityN-Channel
Drain to Source Voltage (Vdss)30V
Current - Continuous Drain (Id) @ 25° C2.5A
Rds On (Max) @ Id, Vgs117 mOhm @ 500mA, 10V
Input Capacitance (Ciss) @ Vds 147pF @ 10V
Power - Max830mW
PackagingTape & Reel (TR)
Gate Charge (Qg) @ Vgs4.6nC @ 10V
Package / CaseSST3 (SOT-23-3)
FET FeatureLogic Level Gate
Drawing Number568; SOT23; ; 3
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names PMV117EN,215
PMV117EN,215
