Product Details

Description



Features:

• Digitial Adaptive Pre-Distortion for wideband linearization of power amplifiers in wireless basestations.
• Digitial Correction for Analog Quadrature Modulation Distortion.
• Digital Soft Pre-compression for efficiency management.
• Input Signal Bandwidth up to 10 MHz. Sample rate up to 80 MHz.
• Programmable, variable input data rate.
• 16-bit microprocessor bus interface for adaptive control processor compensation engine.
• Serial interface (configurable to SPI or I2C operation) for update of power andcarrier values.
• 48 general-purpose IO pins, eight of which are edge-triggered interrupt sources.
• Standard five-signal IEEE 1149.1 JTAG test port for boundary scan board test purposes.






Application

• Multi-carrier WCDMA Base Transceiver Subsystems (BTS).
• CDMA2000 BTS (requires firmware upgrade).
• GSM/TDMA/EDGE BTS (requires firmware upgrade).




Pinout
