PM3388

Features: • Ten port full-duplex Gigabit Ethernet Controller with an industry standard POS-PHY Level 4™ system interface.• Provides direct connection to optics.• Incorporates ten SERDES, compliant with the IEEE 802.3 1998 PMA physical layer specification.• Provides te...

product image

PM3388 Picture
See larger image
SeekIC No. : 004463603 Detail

PM3388: Features: • Ten port full-duplex Gigabit Ethernet Controller with an industry standard POS-PHY Level 4™ system interface.• Provides direct connection to optics.• Incorporates...

PM3388 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PM3388
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Ten port full-duplex Gigabit Ethernet Controller with an industry standard POS-PHY Level 4™ system interface.
• Provides direct connection to optics.
• Incorporates ten SERDES, compliant with the IEEE 802.3 1998 PMA physical layer specification.
• Provides ten standard IEEE 802.3 Gigabit Ethernet MACs for frame verification.
• Provides on-chip data recovery and clock synthesis.
• Provides eight unicast exact-match address filters to filter frames based on DA, DA/VID, SA, or SA/VID.
• Each address filter can indicate whether to accept or discard based on a match.
• Provides 64-group multicast address filter.
• Internal 64 kbyte Tx and 224 kbyte Rx FIFOs per channel provisionable in quantities of 1 kbyte to accommodate system latencies.
• SATURN® compatible interface for Packet-Over-SONET Physical Layer and Link Layer devices Level 4 (POSPHY Level 4 system interface).
• Line side loopback for system level diagnostic capability.
• 16 bit generic microprocessor interface for device initialization, control, register and per port statistics access.




Application

• POS-PHY Level 4 provides consistent system interface for multiple PHY types.
• Edge and Core Routers.
• Multi-Service Switches.
• SONET/SDH Transport Equipment




Pinout
