PJ1-022-SMT

CONN PWR JACK DC 0.65X2.75MM SMD

product image

PJ1-022-SMT Picture
See larger image
SeekIC No. : 003016925 Detail

PJ1-022-SMT: CONN PWR JACK DC 0.65X2.75MM SMD

PJ1-022-SMT Data Sheet

floor Price/Ceiling Price

US $ .38~.8 / Piece | Get Latest Price
Part Number:
PJ1-022-SMT
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~10
  • 10~100
  • 100~500
  • Unit Price
  • $.8
  • $.62
  • $.48
  • $.38
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: - Manufacturer: CUI Inc
Connector Type: Jack Gender: Male
Plug/Mating Plug Diameter: 0.70mm ID, 2.35mm OD (EIAJ-1) Number of Positions/Contacts: 2 Conductors, 3 Contacts
Internal Switch(s): Single Switch, Normally Closed Forward Voltage Drop : 23 V
Mounting Type: Surface Mount, Right Angle Termination: Solder
Shielding: Unshielded Features: -

Description

Series: -
Manufacturer: CUI Inc
Connector Type: Jack
Gender: Male
Number of Positions/Contacts: 2 Conductors, 3 Contacts
Internal Switch(s): Single Switch, Normally Closed
Mounting Type: Surface Mount, Right Angle
Termination: Solder
Shielding: Unshielded
Features: -
Color: Black
Plug/Mating Plug Diameter: 0.70mm ID, 2.35mm OD (EIAJ-1)


Specifications

  • rating: 16 Vdc @ 2.5A
  • contact resistance: 30mΩ at 100mA(max) 1kHz
  • insulation resistance: 100MΩ min.
  • voltage withstand: AC 500V, 50 to 60 Hz for 1 minute
  • center pin diameter: 0.65 mm
  • input hole diameter: 2.80 mm
  • flammability: UL94V-0 rating
  • life: 5,000 cycles
  • 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">



    • Parameters:

    Technical/Catalog InformationPJ1-022-SMT
    VendorCUI Inc (VA)
    CategoryConnectors
    Connector TypeJack
    GenderMale
    Plug/Mating Plug Diameter0.70mm ID, 2.35mm OD (EIAJ-1)
    Signal Lines-
    Number of Positions/Contacts2 Conductors, 3 Contacts
    Mounting TypeSurface Mount, Right Angle
    Features-
    ColorBlack
    TerminationSolder
    Internal Switch(s)Single Switch, Normally Closed
    ShieldingUnshielded
    Lead Free StatusLead Free
    RoHS StatusRoHS Compliant
    Other Names PJ1 022 SMT
    PJ1022SMT
    CP1 022PJCT ND
    CP1022PJCTND
    CP1-022PJCT
