PIC24H

Up to 8 processor exceptions and software traps
7 user-selectable priority levels
Interrupt Vector Table (IVT) with up to 118 vectors
A unique vector for each interrupt or exception source
Fixed priority within a specified user priority level
Alternate Interrupt Vector Table (AIVT) for debug support
Fixed interrupt entry and return latencies

Ambient temperature under bias...................................................................................-40°C to +85°C
Storage temperature ................................................................................................. -65°C to +150°C
Voltage on V_DD with respect to V_SS ................................................................................. -0.3V to +4.0V
Voltage on any combined analog and digital pin and MCLR, with respect to V_SS ... -0.3V to (V_DD + 0.3V)
Voltage on any digital-only pin with respect to V_SS .......................................................... -0.3V to +5.6V
Voltage on V_DDCORE with respect to V_SS ........................................................................ 2.25V to 2.75V
Maximum current out of V_SS pin ...................................................................................................300 mA
Maximum current into V_DD pin (Note 1).........................................................................................250 mA
Maximum output current sunk by any I/O pin....................................................................................4 mA
Maximum output current sourced by any I/O pin ..............................................................................4 mA
Maximum current sunk by all ports ................................................................................................200 mA
Maximum current sourced by all ports (Note 1)..............................................................................200 mA
Note 1: Maximum allowable current is a function of device maximum power dissipation (see Table 23-2).
