PI5C16233C

Storage Temperature ..................................................... 65°C to +150°C
Ambient Temperature with Power Applied ....................40°C to +85°C
Supply Voltage Range ........................................................ 0.5V to +7V
DC Input Voltage ............................................................... 0.5V to +7V
DC Output Current ....................................................................... 120mA
Power Dissipation ............................................................................. 0.5W

Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI5C series of logic circuits are produced using the Company's advanced submicron CMOS technology.
The PI5C16233C is a 16-bit to 32-bit mux/demux switch. This device can be used for memory bank interleaving. The PI5C16233C can be used as two 8-bit to 16-bit multiplexers or as one 16-bit to 32-bit multiplexer.Two select inputs (SEL1 and SEL2) control the data flow. When the TEST inputs are asserted HIGH, the A port is connected to both the B1 and the B2 ports.
