PI3VT34X245

Above which the useful life may be impaired. For user guidelines, not tested.
Storage Temperature ........................................................ 65°C to +150°C
Ambient Temperature with Power Applied ......................... 40°C to +85°C
Supply Voltage to Ground Potential ......................................... 0.5V to +4.6V
DC Input Voltage .................................................................. 0.5V to +5.5V
DC Output Current ............................................................................120mA
Power Dissipation ................................................................................ 0.5W

Note:
Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI3VT34X245 logic circuits are produced using the Company's advanced submicron CMOS technology, achieving industry leading performance.

The PI3VT34X245, is a 2.5V or 3.3V 8-bit, 2-port bus switch, is designed with a low ON resistance (5 ohms). The switches are turned ON or enabled by the Bus Enable (BEn) input signal.Given a 3.3V supply and an input voltage of 3.3V, the switch translates to an output voltage of 2.5V. Similarly, when operated with a 2.5V supply and given 2.5V inputs, the device translates the outputs to 1.8V.
