PI3B32X384

Above which the useful life may be impaired. For user guidelines, not tested.

Storage Temperature ...........................................................65°C to +150°C
Ambient Temperature with Power Applied ............................. 40°C to +85°C
Supply Voltage to Ground Potential ........................................ 0.5V to +4.6V
DC Input Voltage ..................................................................... 0.5V to +4.6V
DC Output Current ............................................................................... 120mA
Power Dissipation ................................................................................... 0.5W

Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI3B32X384 is a 3.3V, 20-bit bus switch designed with a low On-Resistance allowing inputs to be connected directly to outputs. The PI3B32X384 bus switch creates no additional propagational delay or additional ground bounce noise. The switches are turned ON by the Bus Enable (BE) input signal. Four bus enable signals are provided, one for each of the upper and lower five bits of the two 10-bit buses. 3.3V 20-Bit Bus Switch
