PI3B32160

Above which the useful life may be impaired. For user guidelines, not tested.
Storage Temperature............................................................ –65°C to +150°C
Ambient Temperature with Power Applied ........................... –40°C to +85°C
Supply Voltage to Ground Potential (Inputs & VCC Only) ... –0.3V to +4.6V
Supply Voltage to Ground Potential (Outputs & D/O Only) . –0.5V to +4.6V
DC Input Voltage ................................................................... –0.5V to +4.6V
DC Output Current ..............................................................................120mA
Power Dissipation ...................................................................................0.5W
Note:
Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI3B series of logic circuits are produced using the Company's advanced submicron CMOS technology, achieving industry leading performance.

In the  PI3B series ,the PI3B32160 is a 16-bit to 32-bit demultiplexer bus switch. Industry leading advantages include a propagation delay of 250ps, resulting from 5W channel resistance and low I/O capacitance.
A port demultiplexes to either 1B and 2B or to both. The switch is bidirectional.
