PI3B16234

Above which the useful life may be impaired. For user guidelines, not tested.

Storage Temperature ...................................................... 65°C to +150°C
Ambient Temperature with Power Applied ...................... 40°C to +85°C
Supply Voltage Range ....................................................... 0.3V to +4.6V
DC Input Voltage ............................................................... 0.5V to +4.6V
DC Output Current ........................................................................ 120mA
Power Dissipation ............................................................................. 0.5W

Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI3B16234 is a 16-bit to 32-bit mux/demux switch. Industry leading advantages include almost zero propagation delay of 500ps because of 8-ohm channel resistance and low I/O capacitance. A1 port demultiplexes to either port B1 or B2. The PI3B16234 switch is bidirectional.
