PI3B16211

Storage Temperature ...................................................... -65°C to +150°C
Ambient Temperature with Power Applied ........................ -0°C to +85°C
Supply Voltage Range ....................................................... -0.5V to +4.6V
DC Input Voltage ............................................................... -0.5V to +4.6V
DC Output Current ........................................................................ 120 mA
Power Dissipation ............................................................................. 0.5W

Note:Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductorís PI3B series of logic circuits are produced using the Companyís advanced submicron CMOS technology.The PI3B16211 is a 3.3 volt, hot insertion, 24-bit bus switch designed with a low ON resistance allowing inputs to be connected directly to outputs. This PI3B16211 operates as a 24-bit or a as 12-bit bus switch that provides high-speed bus switching.
