Features:

• Light source, lens, and sensor are integrated into a single module
• 11.8 dpm resolution, 104 mm scanning length
• Up to 250 msec/line scanning speed, with 5MHz pixel rate
• Wide dynamic range
• Analog output
• Yellow-green LED light source
• Compact size @ 14 mm x 19 mm x 120 mm
• Low power
• Light weigh


Specifications

Parameter
Symbols
Maximum Rating
Units
Power supply voltage
Vdd
10
V
Idd
50
ma
Vn
-15
V
In
10
ma
VLED
5.5
V
ILED
500
ma
Input clock pulse (high level)
Vih
Vdd 0.5V
V
Input clock pulse (low level)
Vil
-0.6
V



Description

The PI317MC-A6 is a contact imaging sensor, CIS, module, which is composed of 13 PI3021 sensor chips. The PI3021 is a 300 DPI solid-state line imaging array, also a product of Peripheral Imaging Corporation. This imaging device is fabricated using MOS imaging sensor technology for high-speed performance and high sensitivity. The PI317MC-A6 is suitable for scanning A6 size (104 mm) documents with 11.8 dots per millimeter resolution. Applications include ticket, check and card scanners, variety of mark readers, and other automation equipment.
