PI207MC-A4

Features:

• Light source, lens, and sensor are integrated into a single module
• 8 dpm resolution, 216 mm scanning length
• Dual LED light source, IR and Red, with a line scan time to 347 msec @ 5 MHz
• Wide dynamic range
• Analog output
• Compact size @ 14.5 mm x 19.5 mm x 232 mm
• Low power
• Light weight


Specifications

Parameter	Symbols	Maximum Rating	Units
Power supply voltage	Vdd	7	V
	Idd	80	mA
	Vn	-15	V
	In	7	mA
	VLED IR	5.5	V
	VLED RED	5.5	V
	ILED IR	500	mA
	ILED RED	600	mA
Input clock pulse (high level)	Vih	Vdd	V
Input clock pulse (low level)	Vil	-0.5	V

Description

The PI207MC-A4 is a CIS module containing contact image sensors, using MOS image sensor technology for high-speed performance and high sensitivity. The PI207MC-A4 is suitable for scanning A4 size (216 mm) documents with 8 dots per millimeter resolution. Applications include fax machines, game systems, variety of mark readers, and other automation equipment requiring document scanners.
