Product Details

Description



Features:

·NPN Silicon Microwave Power Transistor
·Common Base Configuration
·Broadband Class C Operation
·Interdigitated Geometry
·Diffused Emitter Ballasting Resistors
·Gold Metalization System
·Internal Input Impedance Matching
·Hermetic Metal/Ceramic Package



Specifications

Parameter Symbol Rating Units
Collector-Emitter Voltage VCES 65 V
Emitter-Base Voltage VEBO 3.0 V
Collector Current (Peak) IC 875 mA
Total Power Dissipation PD 17 W
Junction Temperature Tj 200
Storage Temperature TSTG -65 to +200
