PGA4311

V_A . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . .  . . . . . . . . . 5.5V
V_D+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . .  .. . . . . . . . . +5.5V
V_A+ to V_D+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < ± 0.3V
Analog Input Voltage . . . . . . . . . . . . . . . . .  .. . . 0V to V_A+, V_A
Digital Input Voltage . . . . . . . . . . . . . . . . . . . . .  . 0.3V to V_D+
Operating Temperature Range . . . . . . . . . .  . . . 40 to +85
Storage Temperature Range . . . . . . . . . . . . . . 65 to +150
Junction Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . +150
Lead Temperature (soldering, 10s) . . . . . . . . . . . . . . . . . +300
Package Temperature (IR reflow, 10s) . . . . . . . . . . .  . . . +235
(1) Stresses above these ratings may cause permanent damage. Exposure to absolute maximum conditions for extended periods may degrade device reliability.

The PGA4311 is a highperformance, 4-channel audio volume control designed for professional and high-end consumer audio systems. Using high performance operational amplifier stages internal to the PGA4311 yields low noise and distortion, while providing the capability to drive 600 loads directly without buffering. The 3-wire serial control interface allows for connection to a wide variety of host controllers, in addition to support for daisy-chaining of multiple PGA4311 devices.
