Product Details

Description



Features:

·Plastic package has Underwriters Laboratory
Flammability Classification 94V-O Utilizing
Flame Retardant Epoxy Molding Compound
·1.5 ampere operation at TA=55·· with no thermal runaway
·Exceeds environmental standards of MIL-S-19500/228
·Fast switching for high efficiency
·Glass passivated junction in DO-15 package




Specifications

PG150R PG151R PG152R PG154R PG156R PG158R UNITS
Peak Reverse Voltage, Repetitive; VRM 50 100 200 400 600 800 V
Maximum RMS Voltage 35 70 140 280 420 560 V
DC Reverse Voltage; VR 50 100 200 400 600 800 V
Average Forward Current, IO @ TA=55`` 3.8"lead
length 60 Hz, resistive or inductive load		 1.5 A
Peak Forward Surge Current, IFM (surge) 8.3msec.
single half sine wave superimposed on rated
load(JECEC method)		 50 A
Maximum Forward Voltage VF @2.0A, 25`` 1.3 V
Maximum Reverse Current Ta=25``
at Rated DC Blocking Voltage Ta=100``		 5.0
150		 ``A
Typical Junction capacitance (Note 1) CJ 25 PF
Typical Thermal Resistance (Note 3) R ``JA 45 ``/W
Reverse Recovery Time
IF=.5A, IR=1A, Irr=.25A		 150 150 150 150 250 500 ns
Operating and Storage Temperature Range -55 to +150 ``
NOTES:
1. Measured at 1 MHz and applied reverse voltage of 4.0 VDC
2. Thermal resistance from junction to ambient at 0.375"(9.5mm) lead length P.C.B. mounted
