PE83501

The PE83501 is a high-performance dynamic CMOS prescaler with a fixed divide ratio of 2. Its operating frequency range is 400 MHz to 3.5 GHz. The PE83501 operates on a nominal 3 V supply and draws only 12 mA. It is packaged in a small 8-lead MSOP and is ideal for frequency scaling and microwave PLL synthesis solutions.

The PE83501 is manufactured in Peregrine's patented Ultra-Thin Silicon (UTSi) CMOS process, offering the performance of GaAs with the economy and integration of conventional CMOS.
