PE36

PE 36 series is a tpye of 3-bit programmable delay line which has four unique features: The first one is inherent delay which is 3 ns typical. The second one is 16 pin DIP package. The third one is ECL PE 36 series input and output level. The forth one is fan-out 70 ECL capability.

There are some recommended operating conditions about PE 36 series. Supply voltage(VEE) is -5.2 V typ. Ground(Vcc) is 0 V typ. Operating free-air temperature(Ta) is -30 Vmin, +25 V typ and +85 V max. High-level input voltage(VIH) is -0.98 V min.Low-level input voltage(VIL) is -1.63 V max. DC electrical characteristics(25): High-level output voltage(VOH) is -0.96 V min when Vin is the maximum value. Low-level output voltage(Vol) is -1.65 V max when Vin is the minimum value. The high-level input current(IIH) is 265 uA max when Vin is the maximum value.Low-level input current(IIL) is 0.5 uA min when Vin is the minimum vlaue of Vil. SUpply current(Iee) is 60 mA typ and 75 mA max when Vin is open.Input pulse test conditions:Pulse voltage(Ein) is 1 V typ(-0.75 V to -1.75 V). Pulse risetime(TRI) is 2.0 ns max. Pulse width of total delay(TW) is 40% min and 100% typ. Duty cycle(d) is 50% max.

Well, this is a simple introduction to this type of product, if you want to know more about PE 36 series, please pay more attention to our web. Thanks for your attention!
