PDM41256

`  High-speed access times
   Com'l: 7, 8, 10, 12, and 15 ns
   Ind'l: 8, 10, 12, and 15 ns
`  Low power operation (typical)
   -  PDM41256SA
   Active: 400 mW
   Standby: 150 mW
   -  PDM41256LA
   Active: 350 mW
   Standby: 25 mW
`  Single +5V (±10%) power supply
`  TTL-compatible inputs and outputs
`  Packages
   Plastic SOJ (300 mil) - TSO
   Plastic TSOP - T

NOTE: 1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maxi-mum rating conditions for extended periods may affect reliability.

The PDM41256 is a high-performance CMOS static RAM organized as 32,768 x 8 bits. This product is produced in Paradigm's proprietary CMOS technology which offers the designer the highest speed parts. Writing to this device is accomplished when the write enable (WE) and the chip enable (CE) inputs are both LOW. Reading is accomplished when WE remains HIGH and CE and OE are both LOW.

The PDM41256 operates from a single +5V power supply and all the inputs and outputs are fully TTL-compatible. The PDM41256 comes in two versions, the standard power version PDM41256SA and a low power version the PDM41256LA. The two versions are functionally the same and only differ in their power consumption.

The PDM41256 is available in a 28-pin plastic TSOP and a 28-pin 300-mil plastic SOJ.
