PCM1794

Features: 24-Bit Resolution Analog Performance:− Dynamic Range: 132 dB (9 V RMS, Mono)129 dB (4.5 V RMS, Stereo)127 dB (2 V RMS, Stereo)− THD+N: 0.0004% Differential Current Output: 7.8 mA p-p 8* Oversampling Digital Filter:− Stop-Band Attenuation: 130 dB− Pass-Band Ripple...

product image

PCM1794 Picture
See larger image
SeekIC No. : 004456739 Detail

PCM1794: Features: 24-Bit Resolution Analog Performance:− Dynamic Range: 132 dB (9 V RMS, Mono)129 dB (4.5 V RMS, Stereo)127 dB (2 V RMS, Stereo)− THD+N: 0.0004% Differential Current Output: 7.8...

PCM1794 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PCM1794
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

24-Bit Resolution
Analog Performance:− Dynamic Range: 132 dB (9 V RMS, Mono)129 dB (4.5 V RMS, Stereo)127 dB (2 V RMS, Stereo)− THD+N: 0.0004%
Differential Current Output: 7.8 mA p-p
8* Oversampling Digital Filter:− Stop-Band Attenuation: 130 dB− Pass-Band Ripple: ±0.00001 dB
Sampling Frequency: 10 kHz to 200 kHz
System Clock: 128, 192, 256, 384, 512, or768 fS With Autodetect
Accepts 16- and 24-Bit Audio Data
PCM Data Formats: Standard, I2S, andLeft-Justified
Optional Interface Available to ExternalDigital Filter or DSP
Digital De-Emphasis
Digital Filter Rolloff: Sharp or Slow
Soft Mute
Zero Flag
  Dual-Supply Operation:−  5-V Analog, 3.3-V Digital
  5-V Tolerant Digital Inputs
  Small 28-Lead SSOP Package, Lead-FreeProduct


Application

  A/V Receivers
  DVD Players
  Musical Instruments
  HDTV Receivers
  Car Audio Systems
  Digital Multitrack Recorders
  Other Applications Requiring 24-Bit Audio


Pinout

Connection Diagram


Specifications



PCM1793

Supply voltage

VCC1, VCC2L, VCC2R

−0.3 V to 6.5 V

VDD

−0.3 V to 4 V

Supply voltage differences: VCC1, VCC2L and VCC2R

±0.1 V

Ground voltage differences: AGND1, AGND2, AGND3L, AGND3R, and DGND

±0.1 V

Digital input
voltage

LRCK, DATA, BCK, SCK, FMT1, FMT0, MONO, CHSL, DEM, MUTE, RST,

0.3 V to 6.5 V

ZERO

0.3 V to (VDD + 0.3 V) < 4 V

Analog input voltage

0.3 V to (VCC + 0.3 V) <6.5 V

Input current (any pins except supplies)

±10 mA

Ambient temperature under bias

40°C to 125°C

Storage temperature

55°C to 150°C

Junction temperature

150°C

Lead temperature (soldering)

260°C, 5 s

Package temperature (IR reflow, peak)

250°C




Description

The PCM1794 is a monolithic CMOS integrated circuit thatincludes stereo digital-to-analog converters and supportcircuitry in a small 28-lead SSOP package.

The dataconverters PCM1794 use TI's advanced segment DAC architectureto achieve excellent dynamic performance and improvedtolerance to clock jitter. The PCM1794 provides balancedcurrent outputs, allowing the user to optimize analogperformance externally. Sampling rates up to 200 kHz aresupported.
