PC8477B

The PC8477B CMOS advanced floppy disk controller is an enhanced version of National's DP8473 floppy controller. The PC8477B is software compatible with the DP8473 and NEC mPD765 floppy disk controllers. In addition, it is pin and software compatible with the Intel 82077AA floppy controller.

The PC8477B, a 24 MHz crystal, a device chip select, and a resistor package are all that is needed for a complete PC-ATÉ, PS/2É or EISA floppy controller solution. The PC8477B includes advanced features such as a 16 byte FIFO (Burst and Non-Burst modes), support of Perpendicular Recording Mode disk drives, PS/2 diagnostic registers for Model 30 and Models 50/60/80, standard CMOS disk I/O, and additional commands to control these new features. The 16 byte FIFO will increase system performance at higher data rates and with multi-tasking bus structures. PC8477B is designed to fit into all PC-AT, EISA, and PS/2 designs, as well as other advanced applications.
